Script Drawing




Help Section






Primative Drawing





Line


line x,y x,y


Example:
line 100,100 200,50






Rectangle


rect x,y width height


Example:
rect 100,100 200,50






Circle


circle xc,yc radius


Example:
circle 100,100 50






Arc


arc xc,yc radius start_angle end_angle


Example:
arc 100,100 50 0 135






Text


text x,y "text"


Example:
text 100,100 "Hello world"






Leader


leader x,y x,y x,y "text" onright


Example:
leader 100,100 150,150 200,150 "Column C1" true






Poly line


polyline x,y x,y x,y…… radius close


Example:
polyline 100,100 300,100 300,200 400,200 20 false






Dimension alligned


DIMALIGN x,y x,y offset


Example:
dimalign 100,100 100,300 50









Drawing Settings




Sheet Scale


unitscale scale


Example:
unitscale 4






UCS


UCS x,y rotation scale


Example:
UCS 100,100 45 2






Text Align


textAlign "mode"


Example:
textAlign 100,100 "right"






Line Width


lineWidth width


Example:
lineWidth 5






Line Dash Style


setLineDash [l,l,l]


Example:
setLineDash [20,10,5]






Fill Mode


fill true/false"


Example:
fill true






Fill color or pattern


color "value"


Example:
color "red"






Line Color


strokeColor "text"


Example:
strokeColor "black"






Tick size


ticksize arrow dimext


Example:
ticksize 10 10









Advance Drawing




Array input


[v1, v2, v3, v4 ……]


Example:
circle [100, 150, 200, 250],100 50

			circle 100,100 [30,40,50,60]






Mathematic Variable


assign "name" value


Example:
assign "x1" 12.6






Conditional loop


while logical expression …………… do


Example:
assign "x" 0

			while x<100
				line x,100 x+100,100

				assign "x" x+10

			do







Layer


layer "name"


Example:
layer "grid"






Creating block


startblock "name" …………… endblock


Example:
			startblock "marker"
				circle 0,0 30
				rect -10,-10 20,20
			endblock







Inserting block


insert "name" x,y theta scale


Example:
insert "marker" 100,100 45 1
